Hingh-power ceramic packaging LED -3535RGB serie
Maximum drive current :350mA
Low thermal resistance：6℃/W
Wide viewing angle：120°
Unlimited floor life at≥30℃/85RH
Commercial Lighting, Advertising Lighting, Architectural Lighting, Street Lighting, Smart Home Lighting
| Order Codes | Viewing Angle | Color | Min | Typ | Max | ||
|---|---|---|---|---|---|---|---|
| HS-PCBC-107-03 | 30/60/90/120° | R | 620 | - | 625 | ||
| G | 520 | - | 525 | ||||
| B | 455 | - | 465 |
| Parameter | Symbol | Min | Typ | Max | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Viewing Angle | 2θ 1/2 | -- | 120 | -- | deg | IF=350ma |
| Thermal Resistance Junction To Board | RΘJ-B | -- | 6 | -- | ℃/W | IF=350ma |
| Temperature Coefficient of Forward Voltage | ΔVF/ΔT | -- | -2 | -- | mV/℃ | IF=350ma |
| Red Forward Voltage | VF | 2.0 | -- | 2.2 | V | IF=350ma |
| Green Forward Voltage | VF | 3.0 | -- | 3.2 | V | IF=350ma |
| Blue Forward Voltage | VF | 3.0 | -- | 3.2 | V | IF=350ma |
| Reverse Current | IR | ---- | -- | 5 | μA | VR=5V |
Alias： 3535 3w rgb led
